HDMI Repeater 40m Support 3D 1080P (25m input and 15m output)


Introduction


It regenerates the incoming HDMI signal by decoding and re-encoding it to a new standard HDMI signal so it can extend the transmission range without degradation.

Extends 1080p/UXGA up to 40 meter transmission distance(lower resolution signal can be transimitted longer).



Features:
HDMI signal long transmission distance Up to 40m
3D Video Formats1080P,1080i,720P
HDCP 1.4Compliant
HDMI data rate3.4Gbps(single link)
Cable DistanceOver 40m with twisted-Pair
Dimensions(W*H*D)28*13*51mm
Operation FrequencyUp to 340MHZ

Input Video Signal HDMI Signal
HDMI Input/Output ConnectorHDMI Cable
Output VideoHDMI 1.4
Vertical Frequency Range50/60Hz
Video Amplifier Bandwidth2.25Gbps/225MHz
Interlaced Resolutions(50&60Hz)480i,1080i,
Progressive Resolutions(50&60Hz)480p,576p,720p,1080p
Size(L-W-H)28X13X51 mm
Weight (Net)0.02kg
Limited Warranty2 Year Parts and Labor
Operating Temperature0 °C to +70°C
Operating Humidity10%-80%RH(no condensation)
Storage Temperature- -10°C-80°C
Storage Humidity5%-90%RH(no condensation)
External Power SupplyHDMI Cable
Power Consumption3W
Converter UnitFCC,CE.ROHS
User ManualEnglish Version
